2017 MacBook Pro 13 (4TB3) vs. M1 Mac mini - Specs Comparison

Here is a comparison between the specifications of the 2017 MacBook Pro 13 (4TB3) and M1 Mac mini, including differences in the chip, memory, storage, display, battery, ports, and more.

2017 MacBook Pro 13 (4TB3) vs. M1 Mac mini

The 2017 MacBook Pro 13 (4TB3) features the 28W 7th Generation Intel Kaby Lake dual-core Intel Core i5-7267U up to dual-core Intel Core i7-7567U with the boost speed up to 4.00 GHz. While the 2020 M1 Mac mini features the 10W Apple M-Series ARM 64-bit 8-core Apple M1 (8C, 8G) with a clock speed of 3.20 GHz.

If you are in the market looking for a laptop and don't know what's the difference between the 13.3″ 2017 MacBook Pro 13 (4TB3) and the M1 Mac mini (2020), we have a detailed tech specs comparison between both devices for you to check out here.

2017 MacBook Pro 13 (4TB3) vs. M1 Mac mini: Specs Comparison

2017 MacBook Pro 13 (4TB3) image

2017 MacBook Pro 13 (4TB3)

M1 Mac mini image

M1 Mac mini

Key Features
What's new
  • 7th-gen Intel Kaby Lake processor
Availability2017 MacBook Pro 13 (4TB3)M1 Mac mini
Released20172020
Release InfoAnnounced on June 5th, 2017Announced on November 10th, 2020
Pricing
  • $1,799
    Intel Core i5 7267U | 8GB RAM | 256GB SSD
  • $1,999
    Intel Core i5 7267U | 8GB RAM | 512GB SSD
  • $699
    Apple M1 Chip | 8GB RAM | 256GB SSD
  • $899
    Apple M1 Chip | 8GB RAM | 512GB SSD
Display2017 MacBook Pro 13 (4TB3)M1 Mac mini
Size13.3 Inches
InfoRetina display
  • 13.3-inch (diagonal) LED-backlit display with IPS technology; 2560-by-1600 native resolution at 227 pixels per inch with support for millions of colors
  • Supported scaled resolutions:
    • 1680 by 1050
    • 1440 by 900
    • 1024 by 640
  • 500 nits brightness
  • Wide color (P3)
Exterior2017 MacBook Pro 13 (4TB3)M1 Mac mini
Size Comparison
Dimensions11.97” x 8.36” x 0.59” (304.1 mm x 212.4 mm x 14.9 mm)7.7” x 7.7” x 1.4” (197 mm x 197 mm x 36 mm)
WeightStarting at 3.02 lb (1.37 kg)2.6 lb (1.2 kg)
Colors
Space GraySilver
Silver
Keyboard and TrackpadFull-size backlit keyboard with:
  • 64 (U.S.) or 65 (ISO) keys including 4 arrow keys
  • Touch Bar with integrated Touch ID sensor
  • Ambient light sensor
  • Force Touch trackpad for precise cursor control and pressure-sensing capabilities; enables Force clicks, accelerators, pressure-sensitive drawing, and Multi-Touch gestures
Ports4 x Thunderbolt 3
Supports charging, DisplayPort,Thunderbolt (40Gb/s), and USB 3.1 Gen 2 (10Gb/s).
  • Two Thunderbolt / USB 4 ports with support for:
    • DisplayPort
    • Thunderbolt 3 (up to 40Gb/s)
    • USB 3.1 Gen 2 (up to 10Gb/s)
    • Thunderbolt 2, HDMI, DVI, and VGA supported using adapters (sold separately)
  • 2 x USB Type-A ports
    Supports data transfers up to 5 Gbps.
  • 1 x Gigabit Ethernet port
  • 1 x HDMI 2.0
  • 1 x 3.5 mm headphone jack
Internal Specs2017 MacBook Pro 13 (4TB3)M1 Mac mini
Processor
  • 7th Gen Intel® Core™ i5-7267U
    2 cores, 4 threads, 3.10 → 3.50 GHz, 4MB Cache, 28W
  • 7th Gen Intel® Core™ i5-7287U
    2 cores, 4 threads, 3.30 → 3.70 GHz, 4MB Cache, 28W
  • 7th Gen Intel® Core™ i7-7567U
    2 cores, 4 threads, 3.50 → 4.00 GHz, 4MB Cache, 28W
  • Apple M1
    8 cores, 8 threads, 3.20 GHz, 10W
Integrated Graphics
  • 7th Gen Intel® Core™ i5-7267U
    Intel® Iris® Plus Graphics 650
    48 Execution Units with 64 MB eDRAM, 300 → 1050 MHz
  • 7th Gen Intel® Core™ i5-7287U
    Intel® Iris® Plus Graphics 650
    48 Execution Units with 64 MB eDRAM, 300 → 1100 MHz
  • 7th Gen Intel® Core™ i7-7567U
    Intel® Iris® Plus Graphics 650
    48 Execution Units with 64 MB eDRAM, 300 → 1150 MHz
  • Apple M1
    Apple M1 iGPU
    8 Graphics Cores, 1280 MHz
Memory
8GB
configurable to 16GB of 2133MHz LPDDR3 onboard memory
  • 8GB
    4266 MHz LPDDR4X onboard memory
  • Configurable to 16GB
Storage
256GB512GB
configurable to 512GB, 1TB or 2TB SSD
  • 256GB512GB
    SSD
  • Configurable to 1TB or 2TB
Connectivity2017 MacBook Pro 13 (4TB3)M1 Mac mini
Wi-Fi
  • 802.11ac Wi‑Fi wireless networking
  • IEEE 802.11a/b/g/n compatible
  • 802.11ax Wi‑Fi 6 wireless networking
  • IEEE 802.11a/b/g/n/ac compatible
BluetoothBluetooth 4.2 wireless technologyBluetooth 5.0 wireless technology
Ethernet
10/100/1000 BASE-T Gigabit Ethernet (RJ-45 connector)
Battery2017 MacBook Pro 13 (4TB3)M1 Mac mini
Size49.2 Wh lithium‑polymer battery
Battery Life
  • Up to 10 hours wireless web
  • Up to 10 hours Apple TV app movie playback
  • Up to 30 days of standby time
Power Supply61W USB‑C Power Adapter150W built-in power supply
Software2017 MacBook Pro 13 (4TB3)M1 Mac mini
OSShipped with macOS SierraShipped with macOS Catalina
Built-in Apps
PhotosiMovieGarageBandPagesNumbersKeynoteSiriSafariMailFaceTimeMessagesMapsNewsStocksHomeVoice MemosNotesCalendarContactsRemindersPhoto BoothPreviewMusicPodcastsTVBooksApp StoreTime MachineFind MyQuickTime Player
PhotosiMovieGarageBandPagesNumbersKeynoteSiriSafariMailFaceTimeMessagesMapsNewsStocksHomeVoice MemosNotesCalendarContactsRemindersPhoto BoothPreviewMusicPodcastsTVBooksApp StoreTime MachineFind MyQuickTime Player
Camera & Audio2017 MacBook Pro 13 (4TB3)M1 Mac mini
Camera720p FaceTime HD camera
Audio
  • Stereo speakers with high dynamic range
  • Three microphones
  • 3.5mm headphone jack
  • Built-in speaker
  • 3.5mm headphone jack
  • HDMI 2.0 port supports multichannel audio output
Misc2017 MacBook Pro 13 (4TB3)M1 Mac mini
In the box
  • 13‑inch MacBook Pro
  • 61W USB‑C Power Adapter
  • USB-C Charge Cable (2 m)
  • Mac mini
  • Power cord
WarrantyYour MacBook Pro comes with 90 days of complimentary technical support and a one‑year limited warranty. Purchase AppleCare+ for Mac to extend your coverage to three years from your AppleCare+ purchase date and add up to two incidents of accidental damage coverage, each subject to a service fee of $99 for screen damage or external enclosure damage, or $299 for other repairable damage, plus applicable tax.Your Mac mini comes with 90 days of complimentary technical support and a one-year limited warranty. Purchase AppleCare+ for Mac to extend your coverage to three years from your AppleCare+ purchase date and add up to two incidents of accidental damage coverage, each subject to a service fee of $99 for external enclosure damage, or $299 for other repairable damage, plus applicable tax.
More
Video Support
Simultaneously supports full native resolution on the built-in display at millions of colors and:
  • One display with 5120-by-2880 resolution at 60Hz at over a billion colors
  • Up to two displays with 4096-by-2304 resolution at 60Hz at millions of colors
  • Up to two displays with 3840-by-2160 resolution at 60Hz at over a billion colors
Thunderbolt 3 digital video output
  • Native DisplayPort output over USB‑C
  • VGA, HDMI, and Thunderbolt 2 output supported using adapters (sold separately)
Video Support
  • Simultaneously supports up to two displays:
    • One display with up to 6K resolution at 60Hz connected via Thunderbolt and one display with up to 4K resolution at 60Hz connected via HDMI 2.0
  • Thunderbolt 3 digital video output supports
    • Native DisplayPort output over USB‑C
    • Thunderbolt 2, DVI, and VGA output supported using adapters (sold separately)
  • HDMI 2.0 display video output
    • Support for one display with up to 4K resolution at 60Hz
    • DVI output using HDMI to DVI Adapter (sold separately)
